Specification
- Dimensions
- 15,7 x 10,0 x 3,97
- Insert seat
- B06
- Edge Radius (R) [mm]
- 0,8
- fz [mm]
- 0,20 (0,10-0,40)
- vc [m/min] steel
- 220 (160-300)
- vc [m/min] stainless
- 200 (100-300)
- vc [m/min] cast iron
- 260 (200-300)
- Packaging Unit (VPE)
- 10
- prior order number
- FP 47 HT50
- Indication
- N.B.: nominal diameter= +0,2 mm also: side angle 1ø off the perpendicular!
