Specification
- Dimensions
- 15,6 x 10,0 x 3,18
- Insert seat
- B06
- Edge Radius (R) [mm]
- 4,0
- fz [mm]
- 0,20 (0,10-0,30)
- vc [m/min] steel
- 220 (160-300)
- vc [m/min] stainless
- 200 (100-300)
- vc [m/min] cast iron
- 260 (200-300)
- Packaging Unit (VPE)
- 10
- prior order number
- FP 42 R4,0 TA50
- Indication
- Radii require modification of the cutter body!
Media
Kompatible Trägerwerkzeuge
