Specification
- Dimensions
- 12,2x12,2x6,3
- Insert seat
- S05
- Edge Radius (R) [mm]
- 0,8
- fz [mm]
- 0,25 (0,15-0,35)
- vc [m/min] cast iron
- 260 (180-350)
- vc [m/min] highly heat-resistant
- 60 (40-200)
- vc [m/min] tempered
- 80 (40-120)
- Packaging Unit (VPE)
- 10
- prior order number
- FP 91-L HC20
- Indication
- Other edge radiuses can be offered on demand.
