Specification
- Dimensions
- 10,0 x 10,0 x 2,2
- Insert seat
- S02
- Edge Radius (R) [mm]
- 0,4
- fz [mm]
- 0,10 (0,05-0,15)
- vc [m/min] stainless
- 120 (60-180)
- vc [m/min] highly heat-resistant
- 80 (60-120)
- Packaging Unit (VPE)
- 10
- Indication
- Other edge radiuses can be offered on demand.
