Specification
- Dimensions
- 10,0 x 10,0 x 2,2
- Insert seat
- S02
- Edge Radius (R) [mm]
- 0,4
- fz [mm]
- 0,10 (0,05-0,15)
- vc [m/min] cast iron
- 260 (180-350)
- vc [m/min] highly heat-resistant
- 60 (40-200)
- vc [m/min] tempered
- 80 (40-120)
- Packaging Unit (VPE)
- 10
- prior order number
- FP 98-L HT20
- Indication
- Other edge radiuses can be offered on demand.
