Product image 1 of the product “JMA22-584-HC45 ”

JMA22-584-HC45

Product number: A22XD-41-A

Product information
Weight 188.3 kg
Availability This item is not on stock and has to be re-ordered.
JONGEN SERVICE Not quite right for your application? Our modification service adapts standard tools¹ individually to your requirements. ¹ Subject to technical feasibility
JG_ADD_TO_WISHLIST JG_ADD_TO_WISHLIST_SUBTITLE
JONGEN ONE JG_OPEN_IN_CUTTING_CALC JG_CUTTING_CALC_SUBTITLE
Packaging unit
10 piece
JONGEN INFO Alloy surcharge The product shown currently has an alloy surcharge of 47,08 €188.3 g | 100 %
H+M HC45 gesin
Dimensions
IC 16,8x7,32 R1,0
Insert seat
A22
Edge Radius (R) [mm]
1,0
fz [mm]
0,30 (0,15-0,50)
vc [m/min] steel
250 (200-350)
vc [m/min] stainless
240 (140-300)
vc [m/min] cast iron
240 (130-280)
Packaging Unit (VPE)
10
