Product image 1 of the product “JMA22-584-HC30 ”

JMA22-584-HC30

Product number: A22WC-52-A

Product information
Weight 185.6 kg
Availability Ready for shipping
JONGEN SERVICE Not quite right for your application? Our modification service adapts standard tools¹ individually to your requirements. ¹ Subject to technical feasibility
JG_ADD_TO_WISHLIST JG_ADD_TO_WISHLIST_SUBTITLE
JONGEN ONE JG_OPEN_IN_CUTTING_CALC JG_CUTTING_CALC_SUBTITLE
Packaging unit
10 piece
JONGEN INFO Alloy surcharge The product shown currently has an alloy surcharge of 46,40 €185.6 g | 100 %
H+M HC30 gesin
Dimensions
IC 16,8x7,32 R1,0
Insert seat
A22
Edge Radius (R) [mm]
1,0
fz [mm]
0,25 (0,10-0,40)
vc [m/min] steel
160 (120-220)
vc [m/min] stainless
200 (100-300)
vc [m/min] highly heat-resistant
60 (40-200)
Packaging Unit (VPE)
10
